Model number: SQA600.1
Channel / class: Mono / D
RMS power at 1 ohm-14.4V: 600W x 1
RMS power at 2 ohm-14.4V: 420W x 1
RMS power at 4 ohm-14.4V: 240W x 1
Fuse rating: 40A x2
Dimensions (inch): 9.0(w) x 1.9(h) x 7.3(d)
(mm): 228(w) x 48(h) x 185(d)
Unit weight: 6.2 lbs

The SQA Series amplifiers can produce their rated power with an efficiency of more than 80%! These Full Range Class D amplifiers will take it easy on your vehicles charging system while still rocking out to the max. Worry free defensive circuits which detect Short Circuit, Low Battery Voltage, Over Current and Thermal Protection which rollback power from damaging circumstances. The SQA Series have a small footprint for easy installation in tight spaces, and include a robust assortment of crossover adjustments to meet many types of installs and includes a Remote Level Control (1CH, 3CH, and 5CH only) for adjusting the intensity of your bass

PERFORMANCE	SQA600.1
RMS power at 1 ohm (watts x channel)	600 x 1
RMS power at 2 ohm (watts x channel)	420 x 1
RMS power at 4 ohm (watts x channel)	240 x 1
THD at rated RMS power	Less than 0.05%
Signal to noise ratio	>96 dB

FEATURES
Amplifier class	D
Low pass filter	50 – 150 Hz
Subsonic filter	50 – 150 Hz
Bass Boost	0 dB – 18 dB
Fuse rating	40A x 2
Speaker level input	RCA
Width (inch / mm)	9.0 / 228
Height (inch / mm)	1.9 / 48
Depth (inch / mm)	7.3 /185

SQA600.1 | Class D Mono Amplifier 600W X 1 @ 1 ohm

Product Highlights:
