Model Number: FXB101VA
Enclosure Type: Active, Ported
Woofer Size: 10 in.
RMS/MAX Power: 250W / 500W
Frequency Response: 35 Hz – 500 Hz
SPL at 1W / 1m: 92 dB
Impedance: 2 ohm
Dimension (inch): W (15.4) x H (12.8) x D (10.2)

Don’t let the Sub Box small sizes fool you; Cadence loaded enclosures produce tight, rumbling bass you can hear and even feel. They deliver tight, powerful bass that increases the entertainment value of music with a chic, compact design that fits into most trucks or trunks. For even more bass, you can easily connect Cadence master and slave enclosure combinations for double the impact.

GENERAL	FXB101VA
Size	10″
Speaker per Box	1
Cone Material	Black Polypropylene Mica
Surround Material	Butyl Rubber
Voice Coil	1.5” KSV
Enclosure Type	Active Ported
Finish Material	Carpet
Speaker Level Inputs	RCA
Frequency Response	35 Hz – 500 Hz
RMS (watts)	250
Peak Power Handling (watts)	500
Impedance (ohm)	2
Sensitivity (1W / 1mm)	93 dB
Width (inch / mm)	15.4 / 319
Height (inch / mm)	12.8 / 325
Depth (inch / mm)	10.2 / 259

FEATURES
Amplifier Class	Class D
Amplifier RMS (watts)	300
Low Pass Filter	30 Hz – 150 Hz
Fuse Rating	25A x 1

FXB101VA | Single 10” Active Vented Box 500 watts

Product Highlights:

Description
